Continuous hydraulic double piston screen changer for extruder

Technica data

The main body of the screen changer
Raw material: Alloy steel(38CrMoAlA)
Surface treatment: Nitriding treatment
Depth of Nitrated Layer: 0.40-0.70mm
Nitrided hardness: 950-1050Hv
Fragility of nitration: Less than grade 1

Flow channel treatment: Chrome plated
Depth of chromium-plating: 0.05-0.1mm
Hardness of surface after chromium-plating: HV>=950HV

Drive system: Hydraulic unit:


Control system
Electrical controlling system: Warnning device, pressure and temperature transducer, are included


Benifits of this kind of screen changer

1, Double-piston screen changer works simultaneously. One net works. Another replaced; Without interrupting the flow of material and production. And eventually fulfills the exchange of screen without stopping the machine.
2, Exhaust system device can fully defuse the gas mixed in the materials, then improving product quality. And double channels expand the filtration area to meet more productive, more high-quality production need s from customers.

Application fields
. Sheet
. Coating
. Pipe
. Compounding
. Wire and cable
. Tubing
. Textiles(fibers and nonwovens)
. EVA, hot melt adhesive and PSA
. Pelletizing(strands and underwater)
. Recycling of most polymers
. Cast film
. Corrosive and degradable materials
. Textiles (fibers and nonwovens)
